Special Features

•


  1. Tuner
  Input Frequency Range	950 MHz ~ 2150 MHz
  RF Input Signal Level	-85 ~ 25dBM
  RF Impedance	75Ω
  RF Bandwidth	55MHz/8MHz(Under 5 Msps)
  LNB Power	13/18DC, +/-5%, 0.5 Amax 1.8Apeak overloaded protect
  LNB Tone Switch	22KHz +/- 2KHz, 0.65Vp-p+/- 0.15V
  DiSEqC Control	V1.0, V1.2, Tone burst A/B
  2. MPEG
  Transport Stream	MPEG-2 ISO/IEC 13818 Transport Stream Specification
  Input Rate	Max 45Mbit/s
  Video	MPEG-2MP@ML
  Audio	MPEG-1/2 Audio Layer 1 or layer 2
  Aspect Ratio	4:3, 16:9 Auto
  Video Resolution	720x 576(PAL), 720 x 480 (NTSC)
  Audio Mode	Stereo , Dual channel, Joint stereo, Mono
  3. Connector
  LNB IF input	F type, IEC 169-24 Female
  LNB IF Loop- through	F type, IEC 169-24 Female
  TV SCART	CVBS, RGB, AUDIO L,R
  RCA	AUDION L,R CVBS, 0/12V
  4. Power Supply
  Input Voltage	100-240V ~, 50/60Hz.
